技术参数表
备注：
技术参数数据为最大值,并不能同时使用；
超出技术参数范围的使用工况请咨询德威迩公司技术部：0632-5832779-603
产品特点
产品选型表
CatalogModel
|
Max. Pressure¹ |
7500 PSI (515 BAR) |
|
Max. Vacuum¹ |
30 HG |
|
Max. Rotational Speed¹ |
500 RPMPlease note operational life is dependent upon both rotational speed and duty cycle. Contact DSTI if your application requires operating close to the maximum rotational speed with a continuous duty cycle. |
|
Temperature Range¹ |
0° F to 220° F (-18° C to 105° C)² |
|
Part # |
Thru Bore |
Overall Diameter |
Overall Length |
Min Torque* |
Passage Size |
Connection |
Part Downloads |
Quote |
|
GP-130 |
--- |
2.687 |
4.147 |
25 |
0.156 |
1/8"-27 NPT |
|
|
|
GP-131 |
0.500 |
2.937 |
4.186 |
30 |
0.156 |
1/8"-27 NPT |
|
|
|
GP-230 |
--- |
3.187 |
5.290 |
90 |
0.250 |
1/4"-18 NPT |
|
|
|
GP-231 |
0.750 |
3.750 |
5.601 |
100 |
0.250 |
1/4"-18 NPT |
|
|
|
GP-330 |
--- |
3.875 |
6.030 |
100 |
0.375 |
3/8"-18 NPT |
|
|
|
GP-331 |
0.750 |
4.187 |
6.342 |
130 |
0.375 |
3/8"-18 NPT |
|
|
|
GP-430 |
--- |
4.250 |
7.061 |
110 |
0.500 |
1/2"-14 NPT |
|
|
|
GP-431 |
0.750 |
4.937 |
7.406 |
120 |
0.500 |
1/2"-14 NPT |
|
|
|
GP-530 |
--- |
5.250 |
8.280 |
450 |
0.750 |
3/4"-14 NPT |
|
|
|
GP-630 |
--- |
6.937 |
10.570 |
600 |
1.000 |
1"-11.5 NPT |
