技术参数表
备注：
技术参数数据为最大值,并不能同时使用；
超出技术参数范围的使用工况请咨询德威迩公司技术部：0632-5832779-603
产品特点
产品选型表
CatalogModel
|
Max. Pressure¹ |
200 PSI (15 BAR) |
|
Max. Vacuum¹ |
24 HG |
|
Max. Rotational Speed¹ |
75 RPMPlease note operational life is dependent upon both rotational speed and duty cycle. Contact DSTI if your application requires operating close to the maximum rotational speed with a continuous duty cycle. |
|
Temperature Range¹ |
0° F to 220° F (-18° C to 105° C)² |
|
Part # |
Thru Bore |
Overall Diameter |
Overall Length |
Min Torque* |
Passage Size |
Connection |
Part Downloads |
Quote |
|
SCS-605010 |
--- |
2.690 |
3.950 |
10 |
0.620 |
3/4" Type A ASME-BPE |
|
|
|
SCS-606010 |
--- |
3.440 |
4.100 |
25 |
0.870 |
1" Type A ASME-BPE |
|
|
|
SCS-608010 |
--- |
4.440 |
4.640 |
40 |
1.372 |
1.5" Type B ASME-BPE |
|
|
|
SCS-609010 |
--- |
5.440 |
4.990 |
60 |
1.870 |
2" Type B ASME-BPE |
|
|
|
SCS-610010 |
--- |
6.690 |
5.610 |
140 |
2.370 |
2.5" Type B ASME-BPE |
|
|
|
SCS-611010 |
--- |
7.940 |
6.810 |
220 |
2.870 |
3" Type B ASME-BPE |
|
|
|
SCS-613010 |
--- |
8.940 |
7.430 |
340 |
3.834 |
4" Type B ASME-BPE |
|
|
