技术参数表
备注：
技术参数数据为最大值,并不能同时使用；
超出技术参数范围的使用工况请咨询德威迩公司技术部：0632-5832779-603
产品特点
产品选型表
CatalogModel
|
Max. Pressure¹ |
5000 PSI (345 BAR) |
|
Max. Vacuum¹ |
30 HG |
|
Max. Rotational Speed¹ |
50 RPMPlease note operational life is dependent upon both rotational speed and duty cycle. Contact DSTI if your application requires operating close to the maximum rotational speed with a continuous duty cycle. |
|
Temperature Range¹ |
0° F to 220° F (-18° C to 105° C)² |
|
Part # ? |
Thru Bore |
Overall Diameter |
Overall Length |
Min Torque* |
Passage Size |
Connection |
Part Downloads |
Quote |
|
HVH-3561 |
1.000 |
6.938 |
14.743 |
100 |
0.750 |
#12 SAE |
|
|
|
HVH-3661 |
1.000 |
7.438 |
16.243 |
150 |
0.875 |
#16 SAE |
|
|
|
HVH-3761 |
1.000 |
8.938 |
18.652 |
150 |
1.250 |
#20 SAE |
|
|
|
HVH-3861 |
1.000 |
10.938 |
20.104 |
200 |
1.500 |
#24 SAE |
|
